©2005 Maytag Services 16025628 19
Refrigerant Flow
22, 23, 26 cu. ft. Side by Side
Refrigerant Flow Diagram
EVAPORATOR
COMPRESSOR
PROCESS TUBE
CONDENSER
EVAPORATOR
INLET
F
LANGE LOOP
EVAPORATOR OUTLET
SUCTION LINE
HIGH SIDE
DRIER
CAPILLARY TUBE
PROCESS TUBE
C
OMPRESSOR
DISCHARGE
LINE
