6. For ice and water dispensing models only:
Detach main wire connector harness and red wire
harness.
•To detach main wire
harness, use a flat blade
tool or fingernail to press
junction point between two
connectors to release.
•To detach red wire harness,
press tab on underside of
connector to release.
7. Remove top hinges along with doors.
4
Installation
• If tube end is damaged, cut off
5
⁄8" before
reconnecting.
• If leaking occurs, reconnect the line.
8. Remove bottom hinges with a
3
⁄8
" hex head driver.
Replacing the Doors
•To replace the doors, follow the steps in Door and
Hinge Removal in reverse order.
IMPORTANT: If water line tube end is damaged, cut
off
5
⁄
8" before reconnecting.
To Disconnect the Water Line:
•Push in white collar (A) and hold.
•Pull the door-side tube from the connector (B).
To Reconnect the Water Line:
• Firmly push tube
5
⁄8" into the connector. Use
lines on the tube as a guide for full insertion.
Note
•For refrigerators in operation, shut off water before
removing water line from the door.
A
B
3. Close doors.
4. Remove top hinge covers by
removing Phillips screws.
5. Unscrew
5
⁄16" hex head screws from
top hinges.
For water dispensing
models only:
• Do not remove screw
connecting green ground
wire.
