Ice ‘N Water Systems
40 16025628 ©2005 Maytag Services
Troubleshooting of 3 button electronic Ice ‘N Water dispenser
Select WATER, CRUSHED or CUBED mode by pushing the button on the dispenser panel. A green
indicator light above the button indicates the current selection.
Dispenser Light
Light activates at full power when dispensing ice or water.
Table A: Harness 9-pin Connector Configuration
Pin Color Signal
1 GY Ice Door Chute
Solenoid
2 BR Dispenser Light
3 OR Cubed
4 BU Crushed
5 RD Line
6 YL Main Actuator
7 VT Line In
8
9 WH Neutral
Note: All voltage measurements are referenced to line neutral or pin 9 (WH wire) of 9-pin
connector
To Next Page
