22 16025628 ©2005 Maytag Services
22, 23, 26 cu. ft. Model Side by Side
Ice and Water Flow Diagram
Water Valve Diagram
W
ATER TANK
I
NLET 5/16”
ICE MAKER
INLET 1/4”
SOLENOID
VALVE
WATER SUPPLY
HOOKUP
WATER FILTER
INLET
WATER FILTER
OUTLET
DETAIL
