7
Installation
Full-Length Aluminum Handles
To Install:
1. Release top door trim by removing
Phillips screws from top of fresh food
door and retain screws for later use.
2. Align notches on back of handle with
retaining clips on doors. Insert clips
into notches and slide handle
down until it contacts bottom
trim.
3. Replace top door trim and
Phillips screws.
4. Repeat instructions 1-3 to install
other handle.
To avoid possible injury and damage to property,
tape decorative panels (select models) securely into
place before removing door handles.
WARNING
To Remove:
1. Release top door trim by removing
Phillips screws from top of fresh food
door and retain screws for later use.
2. Grasp handle firmly with both hands.
Slide handle upward
approximately
3
⁄4" to release.
3. Repeat instructions 1-2 to
remove other handle.
To Reinstall:
1. Repeat in reverse order.
Door Clip
Wide-by-Side™ Handles
To Install:
1. Align fresh food handle with trim
retainer and door clip.
2. Make sure the tabs of the handle clip
are below the tabs of the door clip.
3. Rotate the handle so that the handle is
flat against the door (see page 6).
4. The tab on the lower part of the handle
will align with the hole in the handle
cap.
5. Slide handle upward until it clicks.
6. Snap top of handle into trim retainer
clip.
7. Repeat for freezer handle.
To Remove:
1. Protect the area above the handle
trim with tape. Insert the tip of a flat blade
screwdriver between the handle trim and door
panel. Carefully pry the trim away from the door
panel.
2. Pull trim free from the trim retainer.
3. Insert door removal card (or
1
⁄32
" thick plastic card))
between the handle and door panel (approximately
1
1
⁄2").
4. Grasp the handle firmly and pull downward to
remove.
5. Repeat for freezer handle.
