Maytag *TC - Cooling; Heat Pump Airflows

36
*TC / TL FURNACES with VARIABLE SPEED BLOWERS
Table 10. Nominal Cooling / Heat Pump Airfl ows (CFM) for Variable Speed Furnaces
“B” CABINET
Switch Settings
(0 = OFF, 1 = ON)
CFM
Nominal A/C
& HP Capacity
HEAT COOL
1-4 5678LOWHIGH
1 0000 485 700
2 TON
1 0001 525 760
1 0010 565 820
2.5 TON
1 0011 605 880
1 0100 650 940
1 0101 6901,000
1 0110 7301,060
3 TON
1 0111 7751,120
1 1000 8151,180
1 1001 8551,240
3.5 TON
1 1010 8951,300
1 1011 9401,360
1 1100 9801,420
1 11011,020 1,480
1 11101,065 1,540
1 11111,105 1,600
“C” CABINET
Switch Settings
(0 = OFF, 1 = ON)
CFM
Nominal A/C
& HP Capacity
HEAT COOL
1-4 5678LOWHIGH
# 0000 7051,025
2.5 TON
# 0001 7501,090
3 TON
# 0010 7951,155
# 0011 8401,220
# 0100 8851,285
3.5 TON
# 0101 9301,350
# 0110 9751,415
4 TON
# 01111,020 1,480
# 10001,065 1,545
# 10011,110 1,610
# 10101,155 1,675
5 TON
# 10111,200 1,740
# 11001,245 1,805
# 11011,290 1,870
# 11101,335 1,935
# 11111,380 2,000
# Switch not used - can be 0 or 1
“D” CABINET
Switch Settings
(0 = OFF, 1 = ON)
CFM
Nominal A/C & HP
Capacity
HEAT COOL
1-4 5678LOWHIGH
# 0000 9651,400
3.5 TON
# 0001 9951,440
4 TON
# 00101,020 1,480
# 00111,050 1,520
# 01001,075 1,560
# 01011,105 1,600
# 01101,130 1,640
# 01111,160 1,680
# 10001,185 1,720
5 TON
# 10011,215 1,760
# 10101,240 1,800
# 10111,270 1,840
# 11001,295 1,880
# 11011,325 1,920
# 11101,350 1,960
# 11111,380 2,000
# Switch not used - can be 0 or 1
