3-17
Knowing Your Mazda
Doors and Locks
Form No. 8S06-EA-03H
When the doors are completely open and
a door is slid by the handle 5 cm (2 in) in
the direction of closing, the doors will
completely close automatically after the
beep sound is heard.
Jam-safe equipment
While a door is opening/closing
electrically and the system detects a
person or an object in the sliding door’s
path, the door will slide in the reverse
direction automatically.
When the power sliding doors are sliding
in the opening direction and an
obstruction is detected in its path, the
beep sound will be heard and the doors
slide in the opposite direction
approximately 10 cm (4 in) and stop.
When the doors are sliding in the closing
direction and an obstruction is detected,
the beep sound will be heard and the
doors open completely.
Power sliding doors main switch
When the power sliding doors main
switch is pressed to the OFF position,
electrical open/close operation is not
possible. The power sliding doors can still
be opened/closed manually.
Check Area Around Power Sliding
Doors Before Operating:
Not checking for occupants and
objects around a power sliding door
before opening/closing it is
dangerous. The jam-safe equipment
is designed to prevent jamming in the
event an obstruction is in the sliding
door’s path. However, if the jam-safe
function detects an obstruction and
slides the door in the reverse
direction, an occupant in the door’s
path could be seriously injured.
Always check the area around the
power sliding doors before opening/
closing them.
WARNING
NOTE
If the power sliding door system
repeatedly detects an obstruction in the
open/close directions for a number of
times, the door will be stopped.
OFF
ON
Power sliding
doors main switch
J16R_8S06-EA-03H_Edition1.book Page 17 Wednesday, July 9, 2003 4:19 PM
