Control Switches
Rear air conditioner main switch
The air conditioner has front and rear
controls. The front air conditioner
controls override the rear controls.
The rear air conditioner main switch is
under the front air conditioner control
panel.
This switch allows variable fan speeds for
the rear air conditioner.
0
—Fan off
REAR
—Select the desired fan speed
with rear air conditioner control panel.
1
—Low speed
2
—Medium speed
3
—High speed
Control Panel (Rear)*
Fan control dial
Fan control dial Mode selector dial
Type A
NOTE:
(Rear heater type)
(Rear cooler type)
Type B
Supplies only hot air
out of floor outlets.
NOTE:
Supplies cold or hot
air out of roof vents
or floor outlets.
Supplies only cold air
out of roof vents.
0123REAR
*Some models.
