Interior Comfort
Climate Control System
Form No. 8S06-EA-03H
â–¼
Control Switches
Temperature control dial
This dial controls temperature. Turn it
clockwise for hot and counterclockwise
for cold.
Fan control dial
This dial allows variable fan speeds.
0—Fan off
1—Low speed
2—Medium low speed
3—Medium high speed
4—High speed
Control Panel (Front)
A/C
0
1
2
3
4
0123REAR
Temperature control dial
A/C switch Rear window defroster switch
Fan control dial
Air intake selector switch
Rear air-conditioner main switch
Mode selector dial
(page 5-38)
(page 6-12)
Cold
Hot
