2-72
Essential Safety Equipment
SRS Air Bags
Form No. 8S06-EA-03H
â–¼
Constant Monitoring
The following components of the air bag
systems are monitored by a diagnostic
system:
•
SAS unit
•
Front air bag sensor
•
Air bag modules
•
Side crash sensor
*
•
Front seat belt pretensioners
•
Related wiring
•
Driver seat slide position sensor
•
Front passenger seat weight sensors
•
Driver and front passenger seat belt
buckle switches
The diagnostic module continuously
monitors the system’s readiness. This
begins when the ignition switch is turned
to the ON position and continues while
the vehicle is being driven.
â–¼
Air Bag/Front Seat Belt
Pretensioner System Warning
Light
If the air bag/front seat belt pretensioner
system is normal, the warning light
illuminates when the ignition switch is
turned to the ON position or after the
engine is cranked. After about 6 seconds it
goes out.
A system malfunction is indicated when
the warning light constantly flashes,
illuminates or doesn’t illuminate at all
when the ignition switch is turned to the
ON position. If any of these occur, do not
allow a person to sit on the front
passenger seat and consult an Authorized
Mazda Dealer as soon as possible. The
system may not work in an accident.
Self-Servicing the Air Bag/
Pretensioner Systems:
Self-servicing or tampering with the
systems is dangerous. An air bag/
pretensioner could accidentally
activate or become disabled. This
could cause serious injuries. Never
tamper with the systems and always
have an Authorized Mazda Dealer
perform all servicing and repairs.
*Some models.
J16R_8S06-EA-03H_Edition1.book Page 72 Wednesday, July 9, 2003 4:19 PM
