Essential Safety Equipment
SRS Air Bags
Form No. 8S06-EA-03H
The supplemental restraint systems (SRS) have two basic subsystems:
•
The air bag system with inflators and air bags.
•
The electric system with crash sensors and diagnostic module.
The air bags are mounted in the following locations:
•
The steering wheel hub
•
The front passenger dashboard
•
The outboard sides of the front seatbacks
The air bags are out of sight until activated.
Supplemental Restraint System Components
