Mazda 6 - Page 8

8
Negative battery cable disconnection
1. Set the selector lever to P range.
(AT vehicles only)
2. Disconnect the negative battery cable and wrap tape around it
to insulate.
Tightening torque : 4.0-6.0 N･m
Trunk covering removal
1. Remove the trunk covering in the direction of arrow (1) shown
in the figure.
Trunk board removal
【With Temporary Spare Tire】
1. Set the trunk covering aside.
2. Remove the trunk board No.1 in the direction of the arrow (1)
shown in the figure.
3. Remove the trunk board No.2 in the direction of the arrow (2)
shown in the figure.
4. Remove the trunk board No.3 in the direction of the arrow (3)
shown in the figure.
6．
V
EHICLE PART REMOVAL
• Be careful not to damage or lose any parts removed from the vehicle since they will be reused.
CAUTION
•
When the negative battery cable is connected during
operation, it may cause electric shock or other personal
injuries. Disconnect the negative battery cable before
removal/installation.
WARNING
•
When removing/installing the parts, park the vehicle on
level ground and apply the side brake securely. Be sure to
turn the ignition switch off, otherwise the vehicle can move,
causing personal injury or vehicle damage.
WARNING
Negative battery cable
Vehicle front
Trunk covering
(1)
Trunk board No.3
Trunk board No.2
Trunk board No.1
(2)
(1)
(3)
