【Without Temporary Spare Tire】
1. Set the trunk covering aside.
2. Remove the trunk board in the direction of the arrow (1) shown in
the figure.
Trunk side pocket removal
1. Remove the fasteners. (LH side only)
2. Remove the trunk side pocket in the direction of the arrow shown
in the figure.
Trunk end trim removal
1. Partially peel back the trunk lid weather strip.
2. Remove fasteners A.
3. Remove fasteners.
Trunk side pocket
Trunk side pocket
Trunk side pocket
Vehicle front
Fasteners
Fasteners
Trunk side trim
Vehicle front
Vehicle front
Fasteners A
Trunk end trim
Weather strip
Trunk side trim removal
Trunk board
(1)
