Mazda CX-7 - Brake Lights;Taillights; Brake Lights;Taillights, Rear Turn Signal Lights, Reverse Lights, Rear Side-Marker Lights; Rear Side-Marker Lights

Black plate (439,1)
7. Rotate the bulb socket
counterclockwise as shown in the
figure and remove it.
8. Install the new bulb in the reverse order
of the removal procedure.
NOTE
l
To replace the bulb, contact an Authorized
Mazda Dealer.
l
If the halogen bulb is accidentally touched,
it should be cleaned with rubbing alcohol
before being used.
l
Use the protective cover and carton for the
replacement bulb to dispose of the old bulb
promptly and out of the reach of children.
Brake lights/Taillight s, Rear turn signal
lights, Reverse lights, Rear side-marker
lights
1. Make sure the ignition is switched off,
and the headlight switch is off.
2. Remove the cover.
3. Turn the socket and bulb assembly
counterclockwise and remove it.
4. Disconnect the bulb from the socket.
Rear side-marker lights
Brake lights/Taillight s
Maintenance and Care
Owner Maintenance
8-47
