Supplemental Restraint System Components
Driver/Front passenger inflators and air bags
Crash and roll-over sensor, and diagnostic module (SAS unit)
Front seat belt pretensioner and load limiting systems (page 2-21)
Front air bag sensor
Side crash sensors
Air bag/front seat belt pretension er system warning light (page 2-54)
Side and curtain inflators and air bags
Front passenger air bag deactivation indicator light (page 2-59)
Front passenger seat weight sensors (page 2-59)
Front passenger seat weight sensor control module
Driver and front passenger seat belt buckle switches (page 2-63)
Driver seat slide position sensor (page 2-59)
2-50
Essential Safety Equipment
SRS Air Bags
