DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
14 P.SLIDE R 20 A Power slide door (RH)
í
15 EHPAS 80 A Power assist steering
16 FOG 15 A Front fog lights
í
17 D.LOCK 20 A Power door lock
18 P.WIND 20 A Power window
19
TCM 15 A ―
AT PUMP 25 A ―
20 HEAD HI 20 A Headlight high beam
21
10 A Engine control system
22 STOP 10 A Brake lights
23
F.WARMER
FUEL PUMP
20 A Fuel system
24 HAZARD 10 A Hazard warning flasher, Direction indicator lights
25 ROOM 15 A Interior lights
26
TAIL
ENG FAN
15 A Tail lights, Position lights, Number plate lights, Rear fog light
í
27 A/C MAG 10 A Magnet clutch
28
ABS V 20 A ABS
HORN 15 A ―
29
SUN ROOF 20 A Sunroof
í
AUDIO1 15 A ―
30
H/CLEAN 30 A ―
DCDC3 25 A ―
31
HORN 15 A Horn
ABS V 20 A ―
32 TAIL 15 A ―
33 ILLUMI 7.5 A Illumination
34 ENG INJ 25 A Engine control system
35 ENG BAR 15 A Engine control system
36 ―― ―
37 M.DEF 7.5 A ―
38 DEFOG 25 A Rear window defroster
39 HEAD LO L 15 A Headlight low beam (LH)
40 HEAD LO R 15 A Headlight low beam (RH)
8-48
Maintenance and Care
í
Some models.
