Mazda MX-5 Miata 2005 - Page 30

Fig. 30: Disconnecting Cables From Rear Of Link
Courtesy of MAZDA MOTORS CORP.
4. Remove the rivets from the link using a drill.
Drill size
4.0 mm diameter {0.16 in diameter}
5. Pr
y
back the bow retainers usin
g
a tape-wrapped flathead screwdriver.
2005 Mazda MX-5 Miata
2005 ACCESSORIES & EQUIPMENT Exterior Trim - MX-5 Miata
