Fig. 40: Installing Set Plate To Link
Courtesy of MAZDA MOTORS CORP.
END PLATE ASSEMBLY NOTE
1. Unfold the convertible top half-way.
2. Pass the cables through the cable guides.
3. Install the cables to the rear of the link.
4. Fold the convertible top.
2005 Mazda MX-5 Miata
2005 ACCESSORIES & EQUIPMENT Exterior Trim - MX-5 Miata
Microsoft
Saturday, July 04, 2009 12:04:28 PM Page 39 © 2005 Mitchell Repair Information Company, LLC.
