Fi
g
. 41: Installin
g
Cables To Rear Of Lin
k
Courtesy of MAZDA MOTORS CORP.
5. Install the top fabric to the link.
6. Unfold the convertible top.
7. Install the end plates to the link.
Fig. 42: Installing Top Fabric To Link
Courtesy of MAZDA MOTORS CORP.
8. Rivet the top fabric to the link.
