Fig. 43: Riveting Top Fabric To Link
Courtesy of MAZDA MOTORS CORP.
RETAINER ASSEMBLY NOTE
1. Install the retainers to the link, ali
nin
the retainer marks with the retainer installation screws.
2005 Mazda MX-5 Miata
2005 ACCESSORIES & EQUIPMENT Exterior Trim - MX-5 Miata
Microsoft
Saturday, July 04, 2009 12:04:28 PM Page 41 © 2005 Mitchell Repair Information Company, LLC.
