Fig. 58: Clamping Top Fabric To Bow
Courtesy of MAZDA MOTORS CORP.
6. Pull the top fabric by hand to verify that it is held securely.
7. Insert a metal rod into the fabric as shown, tie the cable around the rod, and pull the cable through the
fabric.
8. Raise the convertible top as shown in the fi
ure.
2005 Mazda MX-5 Miata
2005 ACCESSORIES & EQUIPMENT Exterior Trim - MX-5 Miata
