1.
1.11 W4000 CE DECLARATION OF CONFORMITY
1.12
W4050 CE DECLARATION OF CONFORMITY
Declaration of Conformity
Directive 2006/42 EC Annex II A
Declaration of Conformity
Directive 2006/42 EC Annex II A
MAZZONI SRL
Via PratiVecchi5
42025 CAVRIAGO (REGGIO EMILIA), ITALY
DECLARES UNDER ITS SOLE RESPONSIBILITY THAT
THEFOLLOWING PRODUCT:
MAZZONI SRL
Via PratiVecchi5
42025 CAVRIAGO (REGGIO EMILIA), ITALY
DECLARES UNDER ITS SOLE RESPONSIBILITY THAT
THEFOLLOWING PRODUCT:
- Machinetype:PressureWasher-Class.no.27annexIpart-Machinetype: PressureWasher-Class.no.27annexIpart
CofItalianLegislative Decree262/02implementing DirectiveCofItalianLegislativeDecree262/02implementingDirective
2000/14/EC
- Model: W4000
- Net installed power (kW):7.5
- Flow rate (l/min):15
- Voltage: 400V
- Frequency: 50Hz
- Measured sound power level LWA (dB):97
- Guaranteed sound power level LWA (dB):98
complies with the provisions of the following EC directives:
2000/14/EC
- Model: W4050
- Net installed power (kW):7.5
- Flow rate (l/min):21
- Voltage: 400V
- Frequency: 50Hz
- Measured sound power level LWA (dB):83
- Guaranteed sound power level LWA (dB):85
complies with the provisions of the following EC directives:
2006/42/EC.....................................................MachineryDirective2006/42/EC. .................................................... MachineryDirective
2014/30/EU.......................ElectromagneticCompatibilityDirective2014/30/EU. ....................... ElectromagneticCompatibilityDirective
2000/14/EC...............................................OutdoorNoiseDirective 2000/14/EC. ............................................. Outdoor NoiseDirective
2014/35/EU...................................................LowVoltageDirective2014/35/EU. ................................................. LowVoltageDirective
ERP2009/125/EC......................Energy-related ProductsDirectiveERP2009/125/EC. .................... Energy-related ProductsDirective
Reference standards:
- UNI EN ISO3744:2010 ........... Determination of sound powerlevels
- UNI EN ISO12100:2010 ......... Safetyofmachinery–Riskassessment
Reference standards:
- UNI EN ISO3744:2010 ........... Determination of sound powerlevels
- UNI EN ISO12100:2010 ......... Safetyofmachinery–Riskassessment
- UNI EN 60335-1:2012-01 ...... Household And Similar Electrical - UNI EN 60335-1:2012-01 ...... Household And SimilarElectrical
Appliances-Safety Appliances -Safety
- CEI EN 60335 – 2-79:2013 .... Particular requirements for high- - CEI EN 60335 – 2-79:2013 .... Particular requirements forhigh-
pressurecleanersandsteamcleaners.
Person authorised to compile the technical file
Moreno Mazzoni
c/o Mazzoni S.R.L.
Official Representative MAZZONI S.R.L.
Barbara Mazzoni
Date: 16 June 2016
pressure cleaners and steam cleaners.
Person authorised to compile the technical file
Moreno Mazzoni
c/o Mazzoni S.R.L.
Official Representative MAZZONI S.R.L.
Barbara Mazzoni
Date: 16 June 2016
A
B
C
6.1 使用步骤
初步检查
在使用高压清洗机之前，请按以下步骤操作：
1. 把机器连接到插座上
2. 将机器连接到水龙头
3. 打开供水
4. 让水从高压软管中流出约20秒，以消除任何可能堵塞喷枪喷嘴的残留物
5. 关闭供水
6. 把喷枪和枪连接起来。
磨合
这台机器要求泵/马达总成有一个短暂的运转周期。正在运行的内容包括：
1. 操作机器不超过一小时
2. 等待机器冷却
3. 重复步骤1和2至少2-3次.
6.2 机器启动
要启动机器，按以下步骤进行（执行初步检查后）：
STEP
ACTION
1
打开供水
2
检查供水线路是否有扭结或堵塞。
3
将高压软管
(A)
连接到喷枪
(B)
。
4
打开喷枪，让喷枪保持几秒钟的开启状态，让管道中的空气和低压水流出(C)。
5
保持喷枪打开，转动启动旋钮（D）或按开始按钮（E）至“1”位置。注意：抓住枪套
用双手紧紧地握住枪。
6
一旦机器启动，你就可以释放喷枪，为将要完成的工作做好准备。
7
在启动过程中要注意压力射流的方向
.
MH3001-3061 MH4000
3025-3040
3060-4000
4000-4050-5000-5025
5050-5090-16/400-6000
E
D
D
W
PH
