10) TECHNICAL DATA
Operating pressure 680 kPa (6.8 bar) (98 psi) max.
Compressed air supply 1000 kPa (10 bar) 145 PSI
Compressed air quality ISO 8573-1:2010 [2:4:2]
Sound level 83 dB
Recommended operating temperature +5°C to +40°C
Relative air humidity 30% to 80% RH (non-condensing)
Transport and storage temperature 0°C to +40°C
Pressure adjustment infinitely variable
Cylinder Ø 100 mm
Cartridge volume 400 ml
Weight 2.5 kg
2
1
1
2
1
2
1
42
53
6
7
1 Compressed air supply 1000 kPa max.
2 Regulator valve 680 kPa
3 Push switch, cylinder forwards
4 Push switch, cylinder backwards
5 Quick exhaust with
silencer (integrated
into the cylinder)
6 Pneumatic Drive Unit
7 Leakage
11) PNEUMATIC DIAGRAM
