McCain FleX M73101S - Page 138

54
d) Pin assignment of the SP1 and SP2 Ports (DB-9 position connector).
SP1 and SP2 , DB-9 pin out
PIN
SIGNAL
1
DCD
2
RxD
3
TxD
4
NC
5
GND
6
NC
7
RTS
8
CTS
9
NC
The unit also has 64 parallel input ports and 64 parallel output ports in the connectors C1S and C11S
located on the Back Panel.
e) Pin assignment of the C11S connector.
C11S connector pin out
PIN
FUNCTION
PIN
FUNCTION
1
O56
19
I52
2
O57
20
I53
3
O58
21
I54
4
O59
22
I55
5
O60
23
I56
6
O61
24
I57
7
O62
25
I58
8
O63
26
I59
9
DGND
27
I60
10
I24
28
I61
11
I25
29
I62
12
I26
30
I63
13
I27
31
DGND
14
DGND
32
N/A
15
I48
33
N/A
16
I49
34
N/A
17
I50
35
N/A
18
I51
36
N/A
37
DGND
