McCain FleX M73101S - Page 61

PART # M59912 REV A
OLD
PART # 1 = M24773
DESCRIPTION:
HARN, SET, FLEX CONTROLLER W/OUT FIO 2 = M46903
No. Type Color P/N Length From Label Finish To Label Finish
1 20 GA 19 STR
RED/WHT M13891 8.5
HOST - 1
GND
1 CTRL SIGNALS - 1 1
2 20 GA 19 STR
RED/WHT M13891 8.5
HOST - 2
GND
1 CTRL SIGNALS - 2 1
3 20 GA 19 STR YELLOW M13945
8.5
HOST - 3 PWR/UP 1 CTRL SIGNALS - 3 1
4 20 GA 19 STR PURPLE M40010
8.5
HOST - 4 PWR/DWN 1 CTRL SIGNALS - 4 1
5 20 GA 19 STR BROWN M40009
8.5
HOST - 5 LINESYNC 1 CTRL SIGNALS - 5 1
6 20 GA 19 STR
RED M13892 8.5
HOST - 7
5 VDC
1 CTRL SIGNALS - 7 1
7 20 GA 19 STR
RED M13892 8.5
HOST - 8
5 VDC
1 CTRL SIGNALS - 8 1
8 20 GA, 19STR BLACK M13846 3.5
CN1-3
AC+ 1 AC OUT-1 1
9 20 GA, 19STR WHITE M13890 3.5
CN1-1
AC- 1 AC OUT-3 1
10 20 GA, 19STR ORANGE M13906 3.5 CN2-1 12VDC 1 DC IN -5 1
11 20 GA, 19STR RED M13892 3.5 CN2-2 5VDC 1 DC IN-4 1
12 20 GA, 19STR
RED/WHT
M13891 3.5 CN2-4 GND 1 DC IN-3 1
13 20 GA, 19STR
RED/WHT
M13891 3.5 CN2-5 GND 1 DC IN-2 1
14 20 GA, 19STR BLACK M13846 5.0 F/S-2 AC+ 1 FUSE-2 2
15 20 GA, 19STR BLACK M13846 5.0 F/S-1 AC+ 1 SWITCH-2 2
16 20 GA, 19STR BLACK M13846 3.0 FUSE-1 AC+ 2 SWITCH-1 2
BLACK 1.5 AC INPUT - 1 AC+ 1 ----
GREEN 1.5 AC INPUT - 3 CHASSIS 1 ----
WHITE 1.5 AC INPUT - 5 AC- 1 ----
* M17371 WILL BE FIRST INSTALLED ON PANEL AND THEN INSERTED INTO "AC IN" HOUSING.
USE WIRE TIE M11960 X 5 EA TO ROUTE HARNESSES.
CONNECTORS: BRAIDS:
F/S= M24665 HOUSING,2POS,SL-156,W/LK 1 EA M13921 EXPANDO BRAID, 1/4", BLACK 0.84 ft (10")
AC OUT=
CN1=
DC IN=
AC IN=
CN2 = M24669 HOUSING,6POS,SL-156,W/LK 1 EA
HOST=
CTRL SIGN.=
Note: Label each connector with its designator by using P-Touch labels.
APP. REV.
A. S. A
M34262
HOUSING,5POS,SL-156,W/LK
2 EA
EC-160025
WIRE LIST
DATE
Nov. 30, 2016
*17
~
AC CORD
M17371
M24670
HOUSING,8POS,SL-156,W/LK
HOSTBOARD TO CONTROL SIGNALS
PS AC TO CONTROL SIGNALS BOARD
PS DC TO CONTROL SIGNALS BOARD
FUSE AND SWITCH
ECN#
2 EA
M24666
2 EA
HOUSING,3POS,SL-156,W/LK
Page 1 of 1
