McCain FleX M73101S - Page 92

1
6
8
7
5
4
2
10
9
2
6
3
3
2
3
A
Isometric View
12
11
1
NEGATIVE POLARITY
POSITIVE POLARITY
DETAIL A
SCALE 2 : 1.5
11
NOTES:
1
2
3
TIGHT THE CAPACITOR PASSING THE
WIRE TIES THRU THE HOLES ON M58996.
DO NOT STRESS WIRES.
CUT 1.5 INCH AND INSTALL ON PCB
BELOW "DC FOR HOST" HEADER AS SHOWN.
CUT TWO GROMMET LINES OF .95 INCH AND
INSTALL ON PANEL AS SHOWN.
Top View
Exploded View
REVISIONS
REV. ECN DESCRIPTION DATE DWN
A1 EC-160036 INITIAL RELEASE DECEMBER 22, 2016 J.G.
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 M59667 BOTTOM PANEL, FLEX RM CONTROLLER 1
2 M11611 SCREW,6-32 X 3/8,PH,PN,SS 5
3 M14679
GROMMET,EDGE .036-.062 C PANDUIT
#GES62F-C
.283ft
4 M59669 BUMPER, PUSH FIT, FOOT 4
5 M58996
PANEL, PWR SUP & CONTROL SIGNALS,
FLEX
1
6 M11706 WASHER, #6, INT. TOOTH, SS 13
7 M58574A ASSY, PCB, CONTROL SIGNALS, FLEX 1
8 M11622 SCREW, 6-32 X 1/4, PH PN SS 8
9 M11966
MT CABLE TIE,SCREW DOWN THOMAS &
BETTS TC828TB
1
10 M45891 ASSY, PWR SUP W/BACKUP HARN 1
11 M11960 WIRE TIE,4",NATURAL TYTON 1
12 M11967 WIRE TIE,8,NATURAL, TYTON 2
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
REV
A1
MODULE, BOTTOM PANEL,
FLEX RM CONTROLLER
SHEET 1 OF 1
CHECKED
DETAILED
PART NUMBER:
2365 OAK RIDGE WAY
VISTA, CA 92081
J.G. 16/01/2017
M59666
SolidWorks file: M59666 MODULE, BOTTOM PANEL, FLEX RM CONTROLLER.SLDDRW
M59666
G.V. 16/01/2017
®
