McCain FleX M73101S - Page 94

This section contains the Flex Shelf Mount Controllers parts list.
“Level 0” means the highest level for an assembly; it is built of parts and/or sub-assemblies that belong to “Level 1”, at the same time such sub-
assemblies could be formed by “Level 2” parts/sub-assemblies and so on, increasing the complexity of the assembly. Assy “A” means that the part
number is a sub-assembly.
Level
A
Part
Number
Description
Rev
Level
Quantity
U of M
Manufacturer
Manufacturer's Part
Number
0
A
M73101S
FLEX SHELF MOUNT CONTROLLER
A
1.00
EA
1
M14691
BUSHING,STRAIN RELIEF - HEYCO #HEY1210
1.00
EA
HEYCO
HEY1210
MOUSER
561MP6P4SPC SRR-10
1
M44730
SCREW,4-40 X 3/8,PH,FH,SS, 100 DEG, BLACK
14.00
EA
1
M58586
SCREW,4-40 X 1/4,PH,FH,SS, 100 DEG, BLACK
4.00
EA
1
A
M58993
TOP PANEL, FLEX CONTROLLER
A
1.00
EA
1
A
M59415
MODULE, BOTTOM PANEL, FLEX CONTROLLER
A1
1.00
EA
1
A
M59890
MODULE, BACK PANEL, FLEX CONTROLLER W/OUT FIO
A
1.00
EA
1
A
M59912
HARN, SET, FLEX CONTROLLER W/OUT FIO
A
1.00
EA
1
A
M73122
MODULE, FRONT PANEL, FLEX CONTROLLER
A
1.00
EA
2
M11622
SCREW,6-32 X 1/4,PH,PN,SS
2.00
EA
2
M11625
SCREW,4-40 X 1/4,PH,PN,SS
10.00
EA
2
M11671
JACKSCREW,4-40 X 1/4,M/F TAP FOR D CONN
2.00
EA
KEYSTONE
7228
2
M11706
WASHER, #6, INT. TOOTH, SS
2.00
EA
2
M11717
WASHER, #4, SPLIT LOCK, SS
10.00
EA
2
M11745
WASHER, #2, INT. TOOTH, SS
6.00
EA
2
M11750
WASHER, #2, FLAT, NYLON .098 ID X.250 OD X.032THK
2.00
EA
KEYSTONE
3347
2
M11783
NUT, HEX, 4-40, KEPNUT, SS
2.00
EA
2
M14838
FUSE,2A,250V,SLO BLO BUSSMAN #MDL2
1.00
EA
BUSSMAN
BK/MDL-2-R
BUSSMAN
MDL-2/BK
BUSSMAN
MDL2
LITTLEFUSE
313002
2
M41113
NUT, 2-56, HEX,SS
6.00
EA
2
M46871
CLIP-ON MOUNTING, CLEAN AND BRIGHT FINISH
1.00
EA
TECH-ETCH
182RF9C070L-2.18-02
2
A
M52284A
ASSY, PCB, 2070-1C, ENGINE
A
1.00
EA
2
M54808
SPACER,#4,3/16L,NYLON
4.00
EA
RAF ELECTRONIC
HARDWARE
1108-4-N
2
M56523
STANDOFF, 4-40 X 11/32", 1/4" Hex, F/F, AL
4.00
EA
RAF ELECTRONIC
HARDWARE
2101T-440-AL
