19
TECHNICAL DATA
Technical data
CS 360T CS 400T CS 420T
Engine
Cylinder displacement, cm
3
36 40 42
Stroke, mm 32 32 32
Idle speed, rpm 3000 3000 3000
Power , kW (Europe) 1,3/9000 1,5/9000 1,6/9000
Ignition system
Spark plug Champion Champion Champion
RCJ--7Y RCJ--7Y RCJ--7Y
Electrode gap, mm 0,5 0,5 0,5
Fuel and lubrication system
Fuel tank capacity , litre 0,3 0,3 0,3
Oil pump capacity at 8,500 rpm, ml/min 4 -- 8 4 -- 8 4 -- 8
Oil tank capacity, litre 0,2 0,2 0,2
Type of oil pump Automatic Automatic Automatic
Weight
Chain saw without bar or chain,
empty tanks, kg 5,5 5,5 5,5
Sound emissions
(see Note 1)
Sound power level, measured dB(A) 108,7 108,7 108,7
Sound power level, guaranteed L
WA
dB(A) 113 113 113
Sound levels
(see Note 2)
Equivalent sound pressure level at the
operators’ ear, dB(A) 99,7 99,7 99,7
Equivalent vibration levels, a
hv,eq
(see Note 3)
Front handle, m/s
2
2,4 2,4 2,4
Rear handle, m/s
2
2,4 2,4 2,4
Chain/bar
Standard bar length, inch/cm 14/35, 16/40, 18/45
Recommended bar lengths, inch/cm 14--18 / 35--45
Usable cutting length, inch/cm 13--17 / 34--44
Pitch, inch 0,375 / 3/8″
Thickness of drive links, inch/mm 0,050/1,3
Type of drive sprocket/number of teeth 6
Chain speed at max. power, m/sec 18,5
Note 1: Noise emissions in the environment measured as sound power (L
WA
) in conformi-
ty with EC directive 2000/14/EC.
Note 2: Equivalent sound pressure level, according to ISO 22868, is calculated as
the time--weighted energy total for different sound pressure levels under various working
conditions. Typical statistical dispersion for equivalent sound pressure level is a standard
deviation of 1 dB(A).
Note 3: Equivalent vibration level, according to ISO 22867, is calculated as the time--
weighted energy total for vibration levels under various working conditions. Reported
data for equivalent vibration level has a typical statistical dispersion (standard deviation)
of 1 m/s
2
.
