MCD Racing RR5 Competition - Mount Ng the a R Ow Set; Mount Ng the Servo Heat Plate

4
Drll 3mm holes
Screw wth 6252
Cut away from the sgn f the Ar Flow Set(7751)
s mounted.
1. Screw the bottom bracket on the engne (6307 - 4mm allen wrench)
2. Screw the man nsulaton plate on the bracket.
(6251, 6307)
3. Screw the man nsulaton plate drectly on the
engne. You don’t need to drll. (6251)
4. Screw the spark plug protecton on the engne.
(6302)
Optonal Barracuda G Performance Exhaust.(7506)
You can only mount the standart
exhaust shown on the pcture.
5. Screw the spark plug protecton on the man
nsulaton plate. (6251)
Mounting the Air Flow Set - 7751 (Optional Part)
Mounting the Servo Heat Plate
6251
PH1 Self Tap 3x9 mm
6302
Hex Screw M4x12 mm
6307
Hex Screw M5x10 mm
