MCD Racing RR5 Competition - Engine and Drivetrain Setup

5
Mounting the Engine
Adjusting the Gear Ratio
Air Filter
APPLY FOAM FILTER OIL!
Be sure the foams rest properly.
Seal the flter wth a plastc safety seal.
Do not use the ar flter wthout olng.
Dust and partcle can damage the engne.
When adjustng the gear rato, dependng on the man gear, set the Gear Mesh Selection Plate and the Brake Plate Stiener
accordng to fgures shown below.
Warnng!
Main Gear: 63T
Brake Plate Stener
Gear Mesh Selecton Plate
19 20 21 22 23 24 Pnon:
Pnon:
24
22
20
23
21
19
Main Gear: 62T
Brake Plate Stener
Gear Mesh Selecton Plate
20 21 22 23 24 25Pnon:
Pnon:
25
23
21
24
22
20
Fuel return
Fuel ntake
6310
Hex Screw M6x20 mm
6307
CH Hex Screw M5x10 mm
6352
CS Hex Screw M5x16 mm
6307
CH Hex Screw M5x10 mm
Default Gear set: Main: 64T, Pinion: 21T
(default ratio: 9,14)
Brake Plate Stener
Gear Mesh Selecton Plate
18 19 20 21 22 23
Pnon:
Pnon:
23
21
19
22
20
18
Fixing the air filter:
You can drll a 2mm hole to fx the ar flter to chasss
wth a body pn.
