IMPORTANT TO THE OPERATOR
Important to the Operator Exploded View (See Figure 10.)
ITEM DESCRIPTION FUNCTION
1 Fan Interlock Switch This switch activates power to the grill and the exhaust fans.
2 ON/OFF Key This key is used to turn the controller on and off to start a
preheating mode and to auto-gap the platen. The key must be
pressed and held for three seconds to activate, in order to
prevent unintended operation.
3 AM/PM Key This key is used to toggle back and forth between the AM and PM
menu item lists.
4 MANUAL/AUTO Key This key is used to toggle back and forth between the Manual
and Auto modes.
5 Left Arrow Key This key is used to scroll through menu items when cooking in the
Manual mode. (Inactive in the Auto mode.)
6 Down Arrow Key While in the Menu mode, this key is used to decrease a numerical
value and to scroll through the characters when entering a new
menu item or modifying an old one. (Inactive in the Auto mode.)
7 OK Key This key is used to accept the information entered.
8 Right Arrow Key This key is used to scroll through menu items when cooking in the
Manual mode. (Inactive in the Auto mode.)
9 Up Arrow Key While in the Menu mode, this key is used to increase a numerical
value and to scroll through the characters when entering a new
menu item or modifying an old one. (Inactive in the Auto mode.)
10 Program Key This key is used to enter and exit the Programming mode.
11 Temperature Key When pressed and held for 3 seconds, this key will access the
Probe Calibration screen.
12 Cook Time Key This key is used to change the remove time of a specific menu
item. To change a specific cook time, the item must be selected in
the Manual mode. (Note: Press and hold the Cook Time key for
three seconds to activate.)
13 Liquid Crystal Display This screen displays menu options and information.
