EQUIPMENT SET-UP PROCEDURES
Installing Upper Platen Release Sheets
1. Slide the release material retention bar
through the loop in the release sheet.
(See Figure 11.)
Figure 11
2. Engage the material retention bar into the
hooks provided on the platen.
(See Figure 12.)
Figure 12
3. Center the release sheet on the bar. Pull
it tightly over the release material bar
located in the front of the platen. Secure
the sheet with two locking clips.
(See Figure 13.)
Figure 13
4. Carefully wrap the release sheet side
flaps over the cover rails and secure the
sheet with locking clips. (See Figure 14.)
Figure 14
IMPORTANT! Do not crease the release
sheet. This will greatly reduce the life
of the sheet.
5. Make sure the release sheets are tight
across the upper platen surface.
6. Repeat these steps for the other upper
platen.
