McDonald's C835 - Page 54

52
140113
Auto Prod Melt Time
This feature allows a one second delay before
the platen is completely lowered into the
cooking position. This feature is used to melt
any ice crystals or deformity in the product.
IMPORTANT! DO NOT adjust the Auto Prod
Melt Time.
1. From the SYSTEM SET UP menu, press
the
key until the screen displays
“AUTO PROD MELT TIME”.
AUTO PROD MELT TIME
1.0
2. Press the keytoreturntothe
AM/PM Mode.
3. Press the
key to exit the
programming mode, or wait for the display
to time out after 3-5 seconds.
Gateway Enabled
The Gateway board was incorporated to be
used with “Smart Equipment.” It allows the
manager to send a LON® service message
out the power line.
IMPORTANT! To enable the Gateway, it
must be enabled on both control panels.
Perform the following steps on one control
panel and then repeat the steps on the other
control panel.
1. From the SYSTEM SET UP menu, press
the
key to scroll t o “GATEWAY
ENABLED Y or N” (YES or NO).
2. Press the
key to change to “Y”
(YES).
3. Press the
key.
4. Press the
key.
5. Press the
key to exit the
programming mode.
6. Repeat these steps on the second
control panel to enable the Gateway on
the entire grill.
7. Shut off the grill for 30 seconds before
attempting to send a service pin.
Sending a Service Pin
1. While in the AM/PM AUTO or MANUAL
Mode, access the Control Menu by
pressing the
key to display
“PROGRAMMING.”
2. Pressing the
key will display the
passcode entry screen.
(Note: No passcode is required.
Proceed to the next step.)
3. Press
key until the SOFTWARE
VERSION is displayed.
4. Press the
key until the GATEWAY
VERSION number appears.
Note: If question marks appear instead of the
Gateway version number, wait a few seconds.
If the version number does not appear, shut
the machine off. After approximately 30
seconds, restart the machine and repeat these
steps.
5. Press the
key to send the service
pin.
6. Press the
key.
7. Press the
key to exit the
programming mode.
