PARTS IDENTIFICATION/FUNCTIONS
C835 Exploded View (See Figure 1)
ITEM
PART NO. DESCRIPTION QTY. FUNCTION WARR.
CLASS
1 X72962 Panel A.-Side Upper
Left
1 Provides access to internal compon-
ents for service and cleaning.
103
2 024298 Screw-10-32 x 3 /8 6 Secures the panel to the frame. 000
3 072967 Panel-Side Left 1 Provides access to internal compon-
ents for service and cleaning.
103
4 X78330-SER Kit A.-Grease Shield 2 Prevents grease migration. 103
4a 078329 Fastener-Snap 16 Fastens grease shields to rear
shroud of grill.
000
4b 078285 Shield-Grease 4 Prevents grease migration. 000
5 X73152 Panel A.-Back
Service (Upper)
1 Provides access to internal compon-
ents for service and cleaning.
103
6 X72958-SER
(Includes
6a-6e)
Panel A.-Back Panel
(Lower)
1 Provides access to internal compon-
ents for service and cleaning. Has a
two speed fan connector built into
the panel.
103
6a 072959 Panel-Back Two
Speed
Fan
1 Provides access to internal compon-
ents. Has a two speed fan connector
built into the panel.
103
6b 053889 Cap-Protective
Plastic 7 /8 THD
1 Protects the plug on the end of the
back panel harness.
000
6c X74158 Harness A.-Back Pnl 1 Connects to the internal harness in
the grill for the 2 speed fan.
103
6d 078327 Nut-Locking Conduit
1/2”
1 Secures the back panel harness
connector to the panel.
000
6e 044823 Connector-Mate Lock 1 Connects the back panel harness to
the internal wire harness.
103
7 X72965 Panel A.-Side Upper
Right
1 Provides access to internal compon-
ents for service and cleaning.
103
8 072968 Panel-Side Right
(Lower)
1 Provides access to internal compon-
ents for service and cleaning.
103
9 078377 Caster-5” 7-5/8 Stem 2 Allows grill mobility. 103
10 073240 Caster-5” Swivel
w/Lock
2 Prevents grill movement. 103
11 X72491-SER Control-Display 2 Controls all functions of the grill. 103
12 076989-WP Switch-Rocker-DPST
10A (Fan Interlock)
1 Activates power to the g rill and the
exhaust fans.
103
13 076012 Button-Operator-
Black (Standby)
2 Activates the cook cycle, keeps the
upper platen in the closed position,
and displays the message
“STANDBY” on the control. When
pressed twice within five seconds,
the upper platen will automatically
lower into the Standby position.
000
14 076011 Button-Operator-Red
(Raise)
2 Cancels the Standby mode, raises
the upper platen, and deactivates the
Cook cycle.
000
