McDSP 6060 Ultimate Module Collection
6060 Plug-in Reference Guide
6060 Specifications
Parameter Range Function
Input and Output
INPUT -24 to +24 dB Gain applied pre module processing
OUTPUT -24 to +24 dB Gain applied post module processing
PHASE +/- 180 degrees Signal polarity adjustment applied post module processing
Compressor Modules
THRESHOLD -48 to 0 dB Signal level at which compression is triggered
RATIO varies by module Amount of compression applied as signal level exceeds
compression threshold
ATTACK varies by module Rate at which compression starts
RELEASE
(RECOVERY)
varies by module Rate at which compression stops
MAKEUP GAIN varies by module Gain applied to signal post compression
FF/FB on/off Source of signal causing compression to trigger. Can
be input (feedforward or FF), or feedback (FB), from
compression output, post compression makeup gain
NEG COMP on/off Negative compression mode enable - causes compressor to
reduce signal output as input levels increase (as opposed to
keeping signal level close to threshold level)
EQ Modules
GAIN -12 to +12 dB Equalizer band gain applied at specified frequency
FREQ varies by module Equalizer band frequency
Expander Modules
THRESHOLD -48 to 0 dB Signal level (post expander HPF and LPF) at which
expansion is triggered
RANGE varies by module Maximum amount of signal level adjustment from
expansion
RATIO varies by module Amount of expansion applied as signal level falls below
selected threshold
ATTACK varies by module Rate at which expansion starts
