Parameter Range Function
SHINE Module
GAIN 0 to 100% Amount of transformer warping to cause pseudo high
frequency boost
MODE Mode 1 or Mode 2 Two types of transformer models
LIFT Lift 1 or Lift 2 Two types of transformer high frequency boost available
per Mode
PDQ Module
PEAK 0 to +12 dB Amount of signal boost oriented around selected frequncy
DIP 0 to -12 dB Amount of signal reduction oriented around selected
frequency
FREQ 1 1.5 to 15 kHz Frequency of peak/dip EQ band 1
FREQ 2 50 to 500 Hz Frequency of peak/dip EQ band 2
WIDE on/off Orientation of peak (boost) and dip (reduction) around
selected frequency
