2 - 1
Overview
Usage Options
l: Pulling pipe from LineTamer and stringing the pipe on
the ground for direct burial (in the trench) or relining an
existing pipeline.
ll: Pulling LineTamer behind vehicle with pipe reel or cage
for stringing out straightened pipe along right of way.
lll: Pulling LineTamer behind vehicle with plowing vehicle
pulling pipe directly into the ground.
lV: Stationary: LineTamer connected to coil trailer with
plowing vehicle pulling a pipe directly into the ground.
V: Stationary: LineTamer connected to coil trailer with
pipe being pulled through existing pipe for relining.
Vl: Stationary: LineTamer connected to coil trailer with
directional boring unit pulling pipe directly into the
ground.
TX00570-9-19-95
I: Stringing Pipe
II: Stringing Pipe
III: Stringing & Planting Pipe
CD00158-8-31-96
CD00198-5-1-96
CD00199-5-1-96
