2 - 4
Pressure Gauges
The pressure gauge on the left indicates pressure on the
rerounding rollers.
The pressure gauge on the right indicates pressure on the
straightening rollers.
TX00978-6-17-96
Hydraulic Controls
(A) Rerounder Pressure Control
(B) Straightener Pressure Control
TX01000-6-27-96
Rerounding Rollers
Pressure to the rerounding rollers is set by a manually operated
control valve.
TX00979-6-17-96
PH00855-6-17-96
PH00854-6-17-96
Straightening Rollers
Pressure to the straightening rollers is set by a manually operated
control valve.
TX00980-6-17-96
PH00471-8-9-95
PH00868-6-26-96
Overview
