4 - 3
Preparation for Pulling
Check Hydraulic Fluid
Periodically check the hydraulic fluid level in reservoir. All
hydraulic cylinders must be retracted before checking fluid to get
an accurate level. Maintain fluid at HIGH Level.
Never allow dirt or foreign matter to enter the open tank.
Refer to the "Hydraulic Fluids" section of this manual for hydraulic
oil recommendations.
TX00966-5-22-96
Straightening Roller
Confirm that the correct straightening roller position is set for
pipe size to be used.
A. Wide roller setting for 4", 5" and 6" pipe.
B. Narrow roller setting for 3" pipe
TX00580-8-10-95
PH00825-5-2-96
CD00156-8-21-95
A
B
