McElroy LineTamer - Pipe Threading and Loading

5 - 3
Pipe Threading Roller Valve
The pipe threading rollers equipped on some trailers can be used
to help guide the starting end of the pipe into the LineTamer.
Use the rollers to pull the pipe down in alignment with the pipe
guide on the LineTamer.
After the pipe is started, move the rollers up to help guide the coil.
TX00987-6-16-96
PH00844-5-17-96
Operation
PH00842-5-17-96
