McIntosh C1000 Service Manual

54
PARTS LIST Cont’d
BALANCE SWITCHING LEFT PCB 050108 (Cont’d)
Ref. No. Description Part No.
Ref. No. Description Part No.
K4 RELAY REED FORM 1A 5V 500 OHMS 087050
K5 RELAY REED FORM 1A 5V 500 OHMS 087050
K6 RELAY REED FORM 1A 5V 500 OHMS 087050
K7 RELAY REED FORM 1C 5V 125 OHM 087056
PCB1 PC BD BAL SWITCHING LEFT 129541
R1 RES MF 47.5K 1% 1/4W 144526
R2 RES MF 1K 1% 1/4W 144513
R3 RES MF 10K 1% 1/4W 144504
R4 RES MF 10K 1% 1/4W 144504
R5 RES MF 2.21 OHM 1/4W 1% 144607
R6 RES MF 2.21 OHM 1/4W 1% 144607
R9 RES MF 47.5 OHM 1% 1/4W 144642
R10 RES MF 47.5K 1% 1/4W 144526
R11 RES MF 2.21 OHM 1/4W 1% 144607
R12 RES MF 2.21 OHM 1/4W 1% 144607
R13 RES MF 47.5 OHM 1% 1/4W 144642
R14 RES MF 47.5K 1% 1/4W 144526
R15 RES MF 4.99K 1% 1/4W 144521
R16 RES MF 4.99K 1% 1/4W 144521
R17 RES MF 2.21 OHM 1/4W 1% 144607
R18 RES MF 2.21 OHM 1/4W 1% 144607
R19 RES MF 10K 1% 1/4W 144504
R20 RES MF 10K 1% 1/4W 144504
R23 RES MF 2.21 OHM 1/4W 1% 144607
R24 RES MF 2.21 OHM 1/4W 1% 144607
R25 RES MF 1K 1% 1/4W 144513
R26 RES MF 267K 1% 1/4W 144532
R27 RES MF 267K 1% 1/4W 144532
R28 RES MF 267K 1% 1/4W 144532
R29 RES MF 1K 1% 1/4W 144513
R30 RES MF 1K 1% 1/4W 144513
ASSY INSERTION PCB BAL SW LEFT 701096
BALANCE SWITCHING RIGHT PCB 050155

C1 CAP ELECT 10UF 50V 066445
C2 CAP MONO 100PF 100V 10% NPO 061341
C3 CAP MONO 100PF 100V 10% NPO 061341
C4 CAP MONO 22PF 200V 10% NPO 061339
C5 CAP MONO 22PF 200V 10% NPO 061339
C6 CAP ELECT 10UF 100VDC 066462
C10 CAP MONO .1UF 50V 20% Z5U 061346
C11 CAP MONO .1UF 50V 20% Z5U 061346
C14 CAP ELECT 47UF 35V 066446
C15 CAP ELECT 47UF 35V 066446
C16 CAP ELECT 47UF 35V 066446
C17 CAP MONO .1UF 50V 20% Z5U 061346
C18 CAP MONO .1UF 50V 20% Z5U 061346
C19 CAP ELECT 10UF 100VDC 066462
C21 CAP MONO 22PF 200V 10% NPO 061339
C22 CAP ELECT 47UF 35V 066446
C23 CAP MONO .1UF 50V 20% Z5U 061346
C24 CAP MONO .1UF 50V 20% Z5U 061346
C25 CAP ELECT 10UF 100VDC 066462
C27 CAP MONO 22PF 200V 10% NPO 061339
C30 CAP MONO 100PF 100V 10% NPO 061341
C31 CAP MONO .1UF 50V 20% Z5U 061346
C32 CAP MONO .1UF 50V 20% Z5U 061346
C35 CAP ELECT 10UF 100VDC 066462
C37 CAP MONO 100PF 100V 10% NPO 061341
C38 CAP MONO 22PF 200V 10% NPO 061339
C39 CAP MONO 22PF 200V 10% NPO 061339
C40 CAP MONO 100PF 100V 10% NPO 061341
C41 CAP MONO 100PF 100V 10% NPO 061341
C42 CAP MONO 100PF 100V 10% NPO 061341
C43 CAP MONO 100PF 100V 10% NPO 061341
C44 CAP ELECT 10UF 50V 066445
C45 CAP ELECT 10UF 50V 066445
C46 CAP ELECT 10UF 50V 066445
D1 DIODE SILICON 070174
IC1 IC OPERATIONAL AMP LOW NOISE 133067
IC2 IC OPERATIONAL AMP LOW NOISE 133067
IC3 IC OPERATIONAL AMP LOW NOISE 133067
IC4 IC OPERATIONAL AMP LOW NOISE 133067
IC5 IC OPERATIONAL AMP LOW NOISE 133067
IC6 IC OPERATIONAL AMP LOW NOISE 133067
J1 CONN 12 PIN FFC 117720
J2 CONN 12 PIN FFC 117720
J3 SOCKET STRIP 14 PIN .025 SQ 117644
J4 SOCKET STRIP 14 PIN .025 SQ 117644
K1 RELAY REED FORM 1A 5V 500 OHMS 087050
K2 RELAY REED FORM 1A 5V 500 OHMS 087050
K3 RELAY REED FORM 1A 5V 500 OHMS 087050
K4 RELAY REED FORM 1A 5V 500 OHMS 087050
K5 RELAY REED FORM 1A 5V 500 OHMS 087050
K6 RELAY REED FORM 1A 5V 500 OHMS 087050
K7 RELAY REED FORM 1C 5V 125 OHM 087056
PCB1 PC BD BALANCE SWITCHING RIGHT 129560
R1 RES MF 47.5K 1% 1/4W 144526
R2 RES MF 1K 1% 1/4W 144513
R3 RES MF 10K 1% 1/4W 144504
R4 RES MF 10K 1% 1/4W 144504
R5 RES MF 2.21 OHM 1/4W 1% 144607
R6 RES MF 2.21 OHM 1/4W 1% 144607
R9 RES MF 47.5 OHM 1% 1/4W 144642
R10 RES MF 47.5K 1% 1/4W 144526
R11 RES MF 2.21 OHM 1/4W 1% 144607
R12 RES MF 2.21 OHM 1/4W 1% 144607
R13 RES MF 47.5 OHM 1% 1/4W 144642
R14 RES MF 47.5K 1% 1/4W 144526
R15 RES MF 4.99K 1% 1/4W 144521
R16 RES MF 4.99K 1% 1/4W 144521
R17 RES MF 2.21 OHM 1/4W 1% 144607
R18 RES MF 2.21 OHM 1/4W 1% 144607
R19 RES MF 10K 1% 1/4W 144504
R20 RES MF 10K 1% 1/4W 144504
R23 RES MF 2.21 OHM 1/4W 1% 144607
R24 RES MF 2.21 OHM 1/4W 1% 144607
R25 RES MF 1K 1% 1/4W 144513
R26 RES MF 267K 1% 1/4W 144532
R27 RES MF 267K 1% 1/4W 144532
R28 RES MF 267K 1% 1/4W 144532
R29 RES MF 1K 1% 1/4W 144513
R30 RES MF 1K 1% 1/4W 144513
ASSY INSERTION PCB BAL RIGHT 701097
METER PCB 050106

C1 CAP MONO .1UF 50V 20% 061346
C2 CAP ELECT 10UF 16V 066580
C3 CAP MONO .1UF 50V 20% 061346
C4 CAP MONO .1UF 50V 20% 061346
C6 CAP ELECT 47UF 16V 6.3X5 CASE 066380
C7 CAP MPF 0.47UF 5% 50/63VDC 064333
C8 CAP MONO .1UF 50V 20% 061346
