McIntosh C1000 Service Manual

TUBE PREAMPLIFIER
C1000
53
PARTS LIST Cont’d
BALANCE I/O LEFT PCB 050198 (Cont’d)
Ref. No. Description Part No.
Ref. No. Description Part No.
R17 RES MF 22.1K 1% 1/4W 144564
R18 RES MF 22.1K 1% 1/4W 144564
R19 RES MF 22.1K 1% 1/4W 144564
R20 RES MF 22.1K 1% 1/4W 144564
R21 RES MF 22.1K 1% 1/4W 144564
R22 RES MF 22.1K 1% 1/4W 144564
ASSY INSERTION PCB BAL I/O L 701079
BALANCE I/O RIGHT PCB 050199

C1 CAP ELECT 10UF 16V T&R 066580
C2 CAP ELECT 10UF 16V T&R 066580
C3 CAP ELECT 10UF 16V T&R 066580
C4 CAP ELECT 10UF 16V T&R 066580
C5 CAP ELECT 10UF 16V T&R 066580
C6 CAP ELECT 10UF 16V T&R 066580
C7 CAP ELECT 47UF 16V 066380
C8 CAP ELECT 47UF 16V 066380
C9 CAP ELECT 47UF 16V 066380
C10 CAP ELECT 47UF 16V 066380
C11 CAP ELECT 47UF 16V 066380
C12 CAP ELECT 47UF 16V 066380
D1 DIODE SILICON 070174
D2 DIODE SILICON 070174
D3 DIODE SILICON 070174
J1 CONN XLR FEM VERT PCB LATCH 117813
J2 CONN XLR FEM VERT PCB LATCH 117813
J3 CONN XLR FEM VERT PCB LATCH 117813
J4 RECEPTACLE XLR MALE 117669
J5 RECEPTACLE XLR MALE 117669
J6 TERMINAL STRIP 14 PIN .025 SQ 117647
J7 TERMINAL STRIP 14 PIN .025 SQ 117647
J8 RECEPTACLE XLR MALE 117669
J9 RECEPTACLE XLR MALE 117669
J10 RECEPTACLE XLR MALE 117669
J11 CONN 12 PIN FFC 117720
K1 RELAY REED FORM 1C 5V 125 OHM 087056
K2 RELAY REED FORM 1A 5V 500 OHMS 087050
K3 RELAY REED FORM 1A 5V 500 OHMS 087050
K4 RELAY REED FORM 1A 5V 500 OHMS 087050
K5 RELAY REED FORM 1A 5V 500 OHMS 087050
K6 RELAY REED FORM 1A 5V 500 OHMS 087050
K7 RELAY REED FORM 1A 5V 500 OHMS 087050
K8 RELAY REED FORM 1A 5V 500 OHMS 087050
K9 RELAY REED FORM 1A 5V 500 OHMS 087050
K10 RELAY REED FORM 1A 5V 500 OHMS 087050
K11 RELAY REED FORM 1A 5V 500 OHMS 087050
K12 RELAY REED FORM 1A 5V 500 OHMS 087050
K13 RELAY REED FORM 1A 5V 500 OHMS 087050
PCB1 PC BD BALANCE I/O RIGHT 129540
R1 RES MF 267K 1% 1/4W 144532
R2 RES MF 267K 1% 1/4W 144532
R3 RES MF 267K 1% 1/4W 144532
R4 RES MF 47.5 OHM 1% 1/4W 144642
R5 RES MF 47.5 OHM 1% 1/4W 144642
R6 RES MF 22.1K 1% 1/4W 144564
R7 RES MF 22.1K 1% 1/4W 144564
R8 RES MF 267K 1% 1/4W 144532
R9 RES MF 267K 1% 1/4W 144532
R10 RES MF 267K 1% 1/4W 144532
R11 RES MF 221 OHM 1% 1/4W 144559
R12 RES MF 221 OHM 1% 1/4W 144559
R13 RES MF 221 OHM 1% 1/4W 144559
R14 RES MF 221 OHM 1% 1/4W 144559
R15 RES MF 221 OHM 1% 1/4W 144559
R16 RES MF 221 OHM 1% 1/4W 144559
R17 RES MF 22.1K 1% 1/4W 144564
R18 RES MF 22.1K 1% 1/4W 144564
R19 RES MF 22.1K 1% 1/4W 144564
R20 RES MF 22.1K 1% 1/4W 144564
R21 RES MF 22.1K 1% 1/4W 144564
R22 RES MF 22.1K 1% 1/4W 144564
ASSY INSERTION PCB BAL I/O R 701095
BALANCE SWITCHING LEFT PCB 050108

C1 CAP ELECT 10UF 50V 066445
C2 CAP MONO 100PF 100V 10% NPO 061341
C3 CAP MONO 100PF 100V 10% NPO 061341
C4 CAP MONO 22PF 200V 10% NPO 061339
C5 CAP MONO 22PF 200V 10% NPO 061339
C6 CAP ELECT 10UF 100VDC 066462
C10 CAP MONO .1uF 50V 20% Z5U 061346
C11 CAP MONO .1uF 50V 20% Z5U 061346
C14 CAP ELECT 47UF 35V 066446
C15 CAP ELECT 47UF 35V 066446
C16 CAP ELECT 47UF 35V 066446
C17 CAP MONO .1uF 50V 20% Z5U 061346
C18 CAP MONO .1uF 50V 20% Z5U 061346
C19 CAP ELECT 10UF 100VDC 066462
C21 CAP MONO 22PF 200V 10% NPO 061339
C22 CAP ELECT 47UF 35V 066446
C23 CAP MONO .1uF 50V 20% Z5U 061346
C24 CAP MONO .1uF 50V 20% Z5U 061346
C25 CAP ELECT 10UF 100VDC 066462
C27 CAP MONO 22PF 200V 10% NPO 061339
C30 CAP MONO 100PF 100V 10% NPO 061341
C31 CAP MONO .1uF 50V 20% Z5U 061346
C32 CAP MONO .1uF 50V 20% Z5U 061346
C35 CAP ELECT 10UF 100VDC 066462
C37 CAP MONO 100PF 100V 10% NPO 061341
C38 CAP MONO 22PF 200V 10% NPO 061339
C39 CAP MONO 22PF 200V 10% NPO 061339
C40 CAP MONO 100PF 100V 10% NPO 061341
C41 CAP MONO 100PF 100V 10% NPO 061341
C42 CAP MONO 100PF 100V 10% NPO 061341
C43 CAP MONO 100PF 100V 10% NPO 061341
C44 CAP ELECT 10UF 50V 066445
C45 CAP ELECT 10UF 50V 066445
C46 CAP ELECT 10UF 50V 066445
D1 DIODE SILICON 070174
IC1 IC OPERATIONAL AMP LOW NOISE 133067
IC2 IC OPERATIONAL AMP LOW NOISE 133067
IC3 IC OPERATIONAL AMP LOW NOISE 133067
IC4 IC OPERATIONAL AMP LOW NOISE 133067
IC5 IC OPERATIONAL AMP LOW NOISE 133067
IC6 IC OPERATIONAL AMP LOW NOISE 133067
J1 CONN 12 PIN FFC 117720
J2 CONN 12 PIN FFC 117720
J3 SOCKET STRIP 14 PIN .025 SQ 117644
J4 SOCKET STRIP 14 PIN .025 SQ 117644
K1 RELAY REED FORM 1A 5V 500 OHMS 087050
K2 RELAY REED FORM 1A 5V 500 OHMS 087050
K3 RELAY REED FORM 1A 5V 500 OHMS 087050
