McIntosh C1000

52
PARTS LIST Cont’d
PHONO PCB 050110 (Cont’d)
Ref. No. Description Part No.
Ref. No. Description Part No.
C31 CAP ELECT 10UF 50V 066445
C32 CAP ELECT 470UF 16V 066508
C33 CAP MONO 220PF 200V 10% NPO 061342
C14 CAP ELECT 10UF 250V 066558
C10 CAP ELECT 100UF 25V 066573
D1 DIODE SILICON 070174
D2 DIODE ZENER 5.1V 070186
D3 DIODE SILICON 070174
D4 DIODE ZENER 5.1V 070186
J1 CONN 12 PIN FFC 117720
J2 CONN 12 PIN FFC 117720
J3 CONN 12 PIN FFC 117720
J4 HEADER 2 PIN LATCHING 117766
Q1 TRANSISTOR SI NPN 25V 132257
Q2 TRANSISTOR SI NPN 25V 132257
Q3 TRANSISTOR SI NPN 25V 132257
Q4 TRANSISTOR SI NPN 25V 132257
PCB1 PC BD PHONO MM 129543
R1 RES MF 47.5K 1% 1/4W 144526
R2 RES MF 1K 1% 1/4W 144513
R3 RES MF 100K 1% 1/4W 144528
R4 RES MF 100K 1% 1/4W 144528
R5 RES MF 10K 1% 1/4W 144504
R6 RES MF 10K 1% 1/4W 144504
R7 RES MF 100K 1% 1/4W 144528
R8 RES MF 100K 1% 1/4W 144528
R9 RES MF 10K 1% 1/4W 144504
R10 RES MF 10K 1% 1/4W 144504
R11 RES MF 95.3 OHM 1% 1/4W 144572
R12 RES MF 2.74K 1% 1/4W 144587
R13 RES MF 475K 1% 1/4W 144604
R14 RES MF 7.5K 1% 1/4W 144571
R15 RES MF 1M 1/4W 144577
R16 RES MF 681 OHM 1% 1/4W 144567
R17 RES MF 150K 1% 1/4W 144627
R18 RES MF 95.3K 1% 1/4W 144538
R19 RES MF 221K 1% 1/4W 144629
R20 RES MF 100K 1% 1/4W 144528
R21 RES MF 2.21 OHM 1/4W 1% 144607
R22 RES MF 2.21 OHM 1/4W 1% 144607
R23 RES MF 22.1K 1% 1/4W 144564
R24 RES MF 182 OHM 1% 1/4W 144579
R26 RES MF 475K 1% 1/4W 144604
R27 RES MF 7.5K 1% 1/4W 144571
R28 RES MF 1M 1/4W 144577
R29 RES MF 681 OHM 1% 1/4W 144567
R30 RES MF 150K 1% 1/4W 144627
R31 RES MF 95.3K 1% 1/4W 144538
R32 RES MF 221K 1% 1/4W 144629
R33 RES MF 2.21 OHM 1/4W 1% 144607
R34 RES MF 2.21 OHM 1/4W 1% 144607
R35 RES MF 22.1K 1% 1/4W 144564
R36 RES MF 20K 1% 1/4W 144524
R37 RES MF 2.74K 1% 1/4W 144587
R38 RES MF 100 OHM 1% 1/4W 144568
R39 RES MF 2.74K 1% 1/4W 144587
R40 RES MF 2.74K 1% 1/4W 144587
R25 RES MF 15K 1% 1/4W 144623
U1 IC OPERATIONAL AMP LOW NOISE 133067
U2 IC OPERATIONAL AMP LOW NOISE 133067
(V1) SOCKET 9 PIN TUBE CERAMIC 178170
(V2) SOCKET 9 PIN TUBE CERAMIC 178170
ASSY INSERTION PCB PHONO 701082
BALANCE I/O LEFT PCB 050198

C1 CAP ELECT 10UF 16V 066580
C2 CAP ELECT 10UF 16V 066580
C3 CAP ELECT 10UF 16V 066580
C4 CAP ELECT 10UF 16V 066580
C5 CAP ELECT 10UF 16V 066580
C6 CAP ELECT 10UF 16V 066580
C7 CAP ELECT 47UF 16V 066380
C8 CAP ELECT 47UF 16V 066380
C9 CAP ELECT 47UF 16V 066380
C10 CAP ELECT 47UF 16V 066380
C11 CAP ELECT 47UF 16V 066380
C12 CAP ELECT 47UF 16V 066380
D1 DIODE SILICON 070174
D2 DIODE SILICON 070174
D3 DIODE SILICON 070174
J1 CONN XLR FEM VERT PCB LATCH 117813
J2 CONN XLR FEM VERT PCB LATCH 117813
J3 CONN XLR FEM VERT PCB LATCH 117813
J4 RECEPTACLE XLR MALE 117669
J5 RECEPTACLE XLR MALE 117669
J6 TERMINAL STRIP 14 PIN .025 SQ 117647
J7 TERMINAL STRIP 14 PIN .025 SQ 117647
J8 RECEPTACLE XLR MALE 117669
J9 RECEPTACLE XLR MALE 117669
J10 RECEPTACLE XLR MALE 117669
J11 CONN 12 PIN FFC 117720
K1 RELAY REED FORM 1C 5V 125 OHM 087056
K2 RELAY REED FORM 1A 5V 500 OHMS 087050
K3 RELAY REED FORM 1A 5V 500 OHMS 087050
K4 RELAY REED FORM 1A 5V 500 OHMS 087050
K5 RELAY REED FORM 1A 5V 500 OHMS 087050
K6 RELAY REED FORM 1A 5V 500 OHMS 087050
K7 RELAY REED FORM 1A 5V 500 OHMS 087050
K8 RELAY REED FORM 1A 5V 500 OHMS 087050
K9 RELAY REED FORM 1A 5V 500 OHMS 087050
K10 RELAY REED FORM 1A 5V 500 OHMS 087050
K11 RELAY REED FORM 1A 5V 500 OHMS 087050
K12 RELAY REED FORM 1A 5V 500 OHMS 087050
K13 RELAY REED FORM 1A 5V 500 OHMS 087050
PCB1 PC BD BALANCED I/O LEFT 129538
R1 RES MF 267K 1% 1/4W 144532
R2 RES MF 267K 1% 1/4W 144532
R3 RES MF 267K 1% 1/4W 144532
R4 RES MF 47.5 OHM 1% 1/4W 144642
R5 RES MF 47.5 OHM 1% 1/4W 144642
R6 RES MF 22.1K 1% 1/4W 144564
R7 RES MF 22.1K 1% 1/4W 144564
R8 RES MF 267K 1% 1/4W 144532
R9 RES MF 267K 1% 1/4W 144532
R10 RES MF 267K 1% 1/4W 144532
R11 RES MF 221 OHM 1% 1/4W 144559
R12 RES MF 221 OHM 1% 1/4W 144559
R13 RES MF 221 OHM 1% 1/4W 144559
R14 RES MF 221 OHM 1% 1/4W 144559
R15 RES MF 221 OHM 1% 1/4W 144559
R16 RES MF 221 OHM 1% 1/4W 144559
