McIntosh C1000

TUBE PREAMPLIFIER
C1000
51
MAIN RIGHT PCB 050111 (Cont’d)
Ref. No. Description Part No.
PARTS LIST Cont’d
Ref. No. Description Part No.
R144 RES MF 1K 1% 1/4W 144513
R145 RES MF 1K 1% 1/4W 144513
R146 RES MF 100 OHM 1% 1/4W 144568
R147 RES MF 100 OHM 1% 1/4W 144568
R148 RES MF 4.75K 1% 1/4W 144520
R149 RES MF 4.75K 1% 1/4W 144520
R150 RES MF 221K 1% 1/4W 144629
R151 RES MF 10K 1% 1/4W 144504
R152 RES MF 2.21K .5% 1/4W 144710
R153 RES MF 221K 1% 1/4W 144629
R154 DIODE ZENER 8.2V 1/2W 070130
R155 RES MF 2.21K .5% 1/4W 144710
R156 RES MF 1M 1% 1/4W 144577
R157 RES MF 475K 1% 1/4W 144604
R160 RES MF 5.36K .5% 1/4W 144615
R161 RES MF 5.36K .5% 1/4W 144615
R162 RES MF 221K 1% 1/4W 144629
R164 RES MF 1M 1% 1/4W 144577
R165 RES MF 475K 1% 1/4W 144604
R168 RES MF 3.79K .5% 1/4W 144711
R169 RES MF 3.79K .5% 1/4W 144711
R170 RES MF 221K 1% 1/4W 144629
R172 RES MF 100K 1% 1/4W 144528
R173 RES MF 100K 1% 1/4W 144528
R174 RES MF 1M 1% 1/4W 144577
R175 RES MF 475K 1% 1/4W 144604
R178 RES MF 2.67K .5% 1/4W 144614
R179 RES MF 221K 1% 1/4W 144629
R180 RES MF 2.67K .5% 1/4W 144614
R182 RES MF 1M 1% 1/4W 144577
R183 RES MF 475K 1% 1/4W 144604
R186 RES MF 1.91K .5% 1/4W 144613
R187 RES MF 1.91K .5% 1/4W 144613
R190 RES MF 2.21 OHM 1/4W 1% 144607
R191 RES MF 2.21 OHM 1/4W 1% 144607
R194 RES MF 6.49K .5% 1/4W 144617
R195 RES MF 6.49K .5% 1/4W 144617
R196 RES MF 3.32K 1% 1/4W 144518
R198 RES MF 2.21 OHM 1/4W 1% 144607
R199 RES MF 2.21 OHM 1/4W 1% 144607
R200 RES MF 1K 1% 1/4W 144513
R201 RES MF 2.21 OHM 1/4W 1% 144607
R202 RES MF 2.21 OHM 1/4W 1% 144607
R203 RES MF 33.2K 1% 1/4W 144694
R204 RES MF 221 OHM 1% 1/4W 144559
R205 RES MF 2.21 OHM 1/4W 1% 144607
R206 RES MF 2.21 OHM 1/4W 1% 144607
R207 RES MF 182 OHM 1/4W 1% 144579
R210 RES MF 33.2K 1% 1/4W 144694
R211 RES MF 33.2K 1% 1/4W 144694
R212 RES MF 6.49K .5% 1/4W 144617
R213 RES MF 221 OHM 1% 1/4W 144559
R214 RES MF 2.21K 1% 1/4W 144584
R220 RES MF 1K 1% 1/4W 144513
U1 IC STEREO DGTL VOLUME CONTROL 133331
U2 IC SHFT REG SER-PAR 133186
U3 IC OCTAL DARLNGTON TRANS ARRAY 133258
(U3) SOCKET IC 18-PIN DIP 178109
U4 IC OCTAL DARLNGTON TRANS ARRAY 133258
(U4) SOCKET IC 18-PIN DIP 178184
U5 IC OCTAL DARLNGTON TRANS ARRAY133258
(U5) SOCKET IC 18-PIN DIP 178184
U6 IC OCTAL DARLNGTON TRANS ARRAY 133258
(U6) SOCKET IC 18-PIN DIP 178184
U7 IC SHFT REG SER-PAR 133186
U8 IC SHFT REG SER-PAR 133186
U9 IC SHFT REG SER-PAR 133186
U10 IC SHFT REG SER-PAR 133186
U11 IC OPERATIONAL AMP LOW NOISE 133067
U12 IC OPERATIONAL AMP LOW NOISE 133067
U13 IC OPERATIONAL AMP LOW NOISE 133067
U14 IC OPERATIONAL AMP LOW NOISE 133067
U15 IC OPERATIONAL AMP LOW NOISE 133067
U16 IC OPERATIONAL AMP LOW NOISE 133067
U17 IC OPERATIONAL AMP LOW NOISE 133067
U18 IC OPERATIONAL AMP LOW NOISE 133067
U19 IC OPERATIONAL AMP LOW NOISE 133067
U20 IC REGULATOR 5V 133250
U21 IC -5V REGULATOR 133598
U22 IC REGULATOR 5V 133250
U23 IC -5V REGULATOR 133598
U24 IC OPERATIONAL AMP LOW NOISE 133067
U25 IC OPERATIONAL AMP LOW NOISE 133067
U26 IC SHFT REG SER-PAR 133186
U27 IC OPERATIONAL AMP LOW NOISE 133067
U28 IC OPERATIONAL AMP LOW NOISE 133067
U29 IC OPERATIONAL AMP LOW NOISE 133067
U30 IC OPERATIONAL AMP LOW NOISE 133067
U31 IC OPERATIONAL AMP LOW NOISE 133067
U32 IC OPERATIONAL AMP LOW NOISE 133067
(V3) SOCKET 9 PIN TUBE CERAMIC 178170
(V4) SOCKET 9 PIN TUBE CERAMIC 178170
ASSY INSERTION PCB MAIN RIGHT 701083
C1 CAP MONO 100PF 100V 10% NPO 061341
C2 CAP MONO 100PF 100V 10% NPO 061341
C3 CAP MONO 47PF 200V 10% NPO 061340
C4 CAP MONO 390PF 5% 200V 061352
C5 CAP MONO 100PF 100V 10% NPO 061341
C6 CAP MONO 47PF 200V 10% NPO 061340
C7 CAP ELECT 470UF 16V 066508
C8 CAP MPF 0.1UF 630VDC 064431
C9 CAP POLYPROP 0.01UF 63V 1% 064444
C11 CAP POLYPROP 0.033UF 63V 2.5% 064446
C12 CAP MPF 0.1UF 630VDC 064431
C13 CAP MONO 22PF 200V 10% NPO 061339
C15 CAP ELECT 10UF 100VDC 066462
C16 CAP MONO .1UF 50V 20% Z5U 061346
C17 CAP MONO .1UF 50V 20% Z5U 061346
C18 CAP MONO 100PF 100V 10% NPO 061341
C19 CAP ELECT 10UF 50V 066445
C20 CAP MONO 220PF 200V 10% NPO 061342
C21 CAP MONO 100PF 100V 10% NPO 061341
C22 CAP MPF 0.1UF 630VDC 064431
C23 CAP POLYPROP 0.01UF 63V 1% 064444
C24 CAP POLYPROP 0.033UF 63V 1% 064446
C26 CAP MPF 0.1UF 630VDC 064431
C27 CAP MONO 22PF 200V 10% NPO 061339
C28 CAP ELECT 10UF 100VDC 066462
C29 CAP MONO .1UF 50V 20% Z5U 061346
C30 CAP MONO .1UF 50V 20% Z5U 061346
PHONO PCB 050110

