Dimensions
Dimensions
The following dimensions can assist in determining the
best location for your C220. There is additional informa-
tion on the next page pertaining to installing the C220 into
cabinets.
17-1/2"
44.45cm
4-5/8"
11.75cm
6"
15.24cm
14-1/2"
36.83cm
15-7/8"
40.32cm
3/16"
0.48cm
4-13/16"
12.22cm
11-1/2"
29.21cm
1"
2.54cm
13-1/4"
33.65cm
17"
43.18cm
5/8"
1.59cm
Front View of the C220
Rear View of the C220
Side View of the C220
5-3/8"
13.69cm
13/16"
2.06cm
75 WATTS
T630maAL 250V
