C2500
79
PARTS LIST cont’d.
CONTROL PCB 751457
Ref No. Description Part No.
Ref No. Description Part No.
3
C10 CAP MONO .1UF 50V 20% SMD0805 061365
C12 CAP ELECT 220UF 25V SMD 066606
C13 CAP ELECT 220UF 25V SMD 066606
C15 CAP MONO .1UF 50V 20% SMD0805 061365
C16 CAP MONO .1UF 50V 20% SMD0805 061365
C22 CAP MONO .1UF 50V 20% SMD0805 061365
C23 CAP MONO .1UF 50V 20% SMD0805 061365
C26 CAP ELECT 470UF 16V SMD 066607
C27 CAP 100PF 50V SMD0805 061316
C28 CAP MONO .1UF 50V 20% SMD0805 061365
C29 CAP MONO .1UF 50V 20% SMD0805 061365
C30 CAP ELECT 470UF 16V SMD 066607
C31 CAP MONO .1UF 50V 20% SMD0805 061365
C32 CAP MONO .1UF 50V 20% SMD0805 061365
C34 CAP ELECT 470UF 16V SMD 066607
C36 CAP MONO .1UF 50V 20% SMD0805 061365
C37 CAP ELECT 10UF 50V SMD 066602
C38 CAP MONO .1UF 50V 20% SMD0805 061365
C39 CAP ELECT 470UF 16V SMD 066607
C40 CAP 100PF 50V SMD0805 061316
C41 CAP ELECT 470UF 16V SMD 066607
C42 CAP MONO .1UF 50V 20% SMD0805 061365
C43 CAP MONO .1UF 50V 20% SMD0805 061365
C44 CAP MONO .1UF 50V 20% SMD0805 061365
C46 CAP MONO .1UF 50V 20% SMD0805 061365
C48 CAP MONO .1UF 50V 20% SMD0805 061365
C49 CAP ELECT 4.7UF 50V SMD 066601
C50 CAP MNO 12pF 50V 5% NPOSMD0805 061364
C51 CAP MNO 12pF 50V 5% NPOSMD0805 061364
C53 CAP .01UF 50V 20% SMD0805 061372
C54 CAP 1000PF 50V SMD0805 061317
C56 CAP MONO .1UF 50V 20% SMD0805 061365
C59 CAP MONO .1UF 50V 20% SMD0805 061365
C60 CAP MONO .1UF 50V 20% SMD0805 061365
C61 CAP MONO .1UF 50V 20% SMD0805 061365
C62 CAP MONO .1UF 50V 20% SMD0805 061365
C63 CAP MONO .1UF 50V 20% SMD0805 061365
C64 CAP ELECT 4.7UF 50V SMD 066601
C65 CAP MONO .1UF 50V 20% SMD0805 061365
C66 CAP MONO .1UF 50V 20% SMD0805 061365
C67 CAP MONO .1UF 50V 20% SMD0805 061365
C68 CAP ELECT 10UF 50V SMD 066602
C71 CAP ELECT 470UF 16V SMD 066607
C72 CAP 100PF 50V SMD0805 061316
C73 CAP MONO .1UF 50V 20% SMD0805 061365
C74 CAP MONO .1UF 50V 20% SMD0805 061365
C75 CAP MONO .1UF 50V 20% SMD0805 061365
C76 CAP MONO .1UF 50V 20% SMD0805 061365
C77 CAP MONO .1UF 50V 20% SMD0805 061365
C78 CAP 100PF 50V SMD0805 061316
C79 CAP MONO .1UF 50V 20% SMD0805 061365
C80 CAP MONO .1UF 50V 20% SMD0805 061365
C81 CAP MONO .1UF 50V 20% SMD0805 061365
C82 CAP MONO .1UF 50V 20% SMD0805 061365
C83 CAP MONO .1UF 50V 20% SMD0805 061365
C84 CAP MONO .1UF 50V 20% SMD0805 061365
C85 CAP MONO .1UF 50V 20% SMD0805 061365
D1 DIODE SMALL SIGNAL 4148 SMD 070199
D3 DIODE SMALL SIGNAL 4148 SMD 070199
D5 DIODE ESD SUPPRESSOR SMD 070198
D6 DIODE ESD SUPPRESSOR SMD 070198
D7 DIODE ESD SUPPRESSOR SMD 070198
D8 DIODE ESD SUPPRESSOR SMD 070198
D9 DIODE ESD SUPPRESSOR SMD 070198
D10 DIODE ESD SUPPRESSOR SMD 070198
D11 DIODE ESD SUPPRESSOR SMD 070198
D22 DIODE SMALL SIGNAL 4148 SMD 070199
D28 DIODE ESD SUPPRESSOR SMD 070198
D29 DIODE ESD SUPPRESSOR SMD 070198
D30 DIODE ESD SUPPRESSOR SMD 070198
D31 DIODE ESD SUPPRESSOR SMD 070198
D32 DIODE ESD SUPPRESSOR SMD 070198
D33 DIODE ESD SUPPRESSOR SMD 070198
D34 DIODE ESD SUPPRESSOR SMD 070198
D35 DIODE ESD SUPPRESSOR SMD 070198
D36 DIODE ESD SUPPRESSOR SMD 070198
D37 DIODE ESD SUPPRESSOR SMD 070198
D38 DIODE ESD SUPPRESSOR SMD 070198
D39 DIODE ESD SUPPRESSOR SMD 070198
D40 DIODE ESD SUPPRESSOR SMD 070198
D42 DIODE ESD SUPPRESSOR SMD 070198
D43 DIODE ESD SUPPRESSOR SMD 070198
D44 DIODE SMALL SIGNAL 4148 SMD 070199
D45 DIODE SMALL SIGNAL 4148 SMD 070199
D46 DIODE SMALL SIGNAL 4148 SMD 070199
D47 DIODE SMALL SIGNAL 4148 SMD 070199
D48 DIODE SMALL SIGNAL 4148 SMD 070199
D49 DIODE ESD SUPPRESSOR SMD 070198
D50 DIODE ESD SUPPRESSOR SMD 070198
DS1 IR LED EMITTER 058174
(DS1) SPACER LED 112108
DS2 LED WHITE SMD 058193
DS3 LED WHITE SMD 058193
DS4 LED WHITE SMD 058193
DS5 LED WHITE SMD 058193
DS6 LED WHITE SMD 058193
DS7 LED WHITE SMD 058193
F1 FUSE 0.35A 16V RESET 1206 SMD 145054
F2 FUSE 0.35A 16V RESET 1206 SMD 145054
F3 RESETTABLE FUSE 750mA SMD 145046
F4 RESETTABLE FUSE 750mA SMD 145046
F6 RESETTABLE FUSE 750mA SMD 145046
F7 RESETTABLE FUSE 750mA SMD 145046
F9 RESETTABLE FUSE 750mA SMD 145046
F10 FUSE 0.35A 16V RESET 1206 SMD 145054
F11 FUSE 0.35A 16V RESET 1206 SMD 145054
F12 RESETTABLE FUSE 750mA SMD 145046
F13 RESETTABLE FUSE 750mA SMD 145046
GP3 TERMINAL PC SCREW 117975
J5 CONN 12 PIN FFC SMD 118001
J6 7PIN SHROUDED HEADER 117910
J7 7PIN SHROUDED HEADER 117910
J11 CONN 12 PIN FFC SMD 118001
J12 CONN 12 PIN FFC SMD 118001
J13 JACK HEADPHONE DUAL BLACK 1/8 117825
J14 JACK HEADPHONE DUAL BLACK 1/8 117825
J15 JACK HEADPHONE DUAL BLACK 1/8 117825
J16 JACK HEADPHONE DUAL BLACK 1/8 117825
