McIntosh C2500 - Page 44

80
PARTS LIST cont’d.
CONTROL PCB 751457 (Cont’d.)
Ref No. Description Part No.
Ref No. Description Part No.
3
J17 JACK HEADPHONE DUAL BLACK 1/8 117825
J18 JACK HEADPHONE DUAL BLACK 1/8 117825
J19 JACK HEADPHONE DUAL BLACK 1/8 117825
J20 JACK HEADPHONE DUAL BLACK 1/8 117825
J21 CONN 12 PIN FFC SMD 118001
J22 CONN 12 PIN FFC SMD 118001
J23 CONN 12 PIN FFC SMD 118001
J25 CONN 9 PIN SUB D 117902
J4 CONN 13 PIN FFC SMD 118002
J2 CONN 18 PIN FFC SMD 118003
J24 CONNECTOR 3PIN HEADER 2MM 118013
L2 FERRITE 600 OHM 0.5 AMP SMD 076026
L4 FERRITE 600 OHM 0.5 AMP SMD 076026
L5 FERRITE 60 OHM 5 AMP SMD 076025
L6 FERRITE 60 OHM 5 AMP SMD 076025
L7 FERRITE 60 OHM 5 AMP SMD 076025
L8 FERRITE 60 OHM 5 AMP SMD 076025
L9 FERRITE 60 OHM 5 AMP SMD 076025
L10 FERRITE 60 OHM 5 AMP SMD 076025
L12 FERRITE 600 OHM 0.5 AMP SMD 076026
L13 FERRITE 600 OHM 0.5 AMP SMD 076026
L14 FERRITE 600 OHM 0.5 AMP SMD 076026
L15 FERRITE 600 OHM 0.5 AMP SMD 076026
L16 FERRITE 600 OHM 0.5 AMP SMD 076026
L17 FERRITE 600 OHM 0.5 AMP SMD 076026
L18 FERRITE 600 OHM 0.5 AMP SMD 076026
L19 FERRITE 600 OHM 0.5 AMP SMD 076026
L20 FERRITE 600 OHM 0.5 AMP SMD 076026
L21 FERRITE 600 OHM 0.5 AMP SMD 076026
L22 FERRITE 600 OHM 0.5 AMP SMD 076026
L23 FERRITE 600 OHM 0.5 AMP SMD 076026
L24 FERRITE 600 OHM 0.5 AMP SMD 076026
L25 FERRITE 600 OHM 0.5 AMP SMD 076026
L26 FERRITE 600 OHM 0.5 AMP SMD 076026
L27 FERRITE 600 OHM 0.5 AMP SMD 076026
L29 FERRITE 60 OHM 5 AMP SMD 076025
L30 FERRITE 600 OHM 0.5 AMP SMD 076026
L31 FERRITE 600 OHM 0.5 AMP SMD 076026
L32 FERRITE 600 OHM 0.5 AMP SMD 076026
L33 FERRITE 600 OHM 0.5 AMP SMD 076026
L34 FERRITE 600 OHM 0.5 AMP SMD 076026
L35 FERRITE 600 OHM 0.5 AMP SMD 076026
L36 FERRITE 600 OHM 0.5 AMP SMD 076026
L37 FERRITE 600 OHM 0.5 AMP SMD 076026
L39 FERRITE 600 OHM 0.5 AMP SMD 076026
L40 FERRITE 600 OHM 0.5 AMP SMD 076026
MT1 SENSOR IR 38KHZ 3V-5V 121067
PCB1 PCB CONTROL 130177
Q1 TRANSISTOR NPN A05 SMD 132333
Q2 TRANSISTOR NPN A05 SMD 132333
Q3 TRANSISTOR NPN A05 SMD 132333
Q4 TRANSISTOR NPN A05 SMD 132333
Q5 TRANSISTOR NPN A05 SMD 132333
Q6 TRANSISTOR NPN A05 SMD 132333
Q7 TRANSISTOR NPN A05 SMD 132333
Q8 TRANSISTOR NPN A05 SMD 132333
Q9 TRANSISTOR NPN A05 SMD 132333
Q10 TRANSISTOR NPN A05 SMD 132333
Q11 TRANSISTOR NPN A05 SMD 132333
Q12 TRANSISTOR NPN A05 SMD 132333
Q13 TRANSISTOR NPN A05 SMD 132333
Q14 TRANSISTOR NPN A05 SMD 132333
Q15 TRANSISTOR NPN A05 SMD 132333
Q16 TRANSISTOR NPN A05 SMD 132333
Q17 TRANSISTOR NPN A05 SMD 132333
Q18 TRANSISTOR NPN A05 SMD 132333
Q19 TRANSISTOR NPN A05 SMD 132333
Q20 TRANSISTOR NPN A05 SMD 132333
Q21 TRANSISTOR NPN A05 SMD 132333
Q22 TRANSISTOR NPN A05 SMD 132333
Q23 TRANSISTOR NPN A05 SMD 132333
Q25 TRANSISTOR NPN A05 SMD 132333
Q26 TRANSISTOR NPN A05 SMD 132333
Q27 TRANSISTOR NPN A05 SMD 132333
Q28 TRANSISTOR NPN A05 SMD 132333
Q29 TRANSISTOR NPN A05 SMD 132333
Q30 TRANSISTOR NPN A05 SMD 132333
Q31 TRANSISTOR NPN A05 SMD 132333
Q32 TRANSISTOR NPN A05 SMD 132333
Q33 TRANSISTOR NPN A05 SMD 132333
R1 RES SMD0805 47.5K 1/8W 1% 145013
R2 RES SMD0805 1K 1/8W 1% 145007
R3 RES SMD0805 4.75K 1/8W 1% 145008
R4 RES SMD0805 47.5K 1/8W 1% 145013
R5 RES SMD0805 1K 1/8W 1% 145007
R6 RES SMD0805 10 1/8W 1% 145017
R7 RES SMD0805 100 1/8W 1% 145005
R8 RES SMD0805 22.1K 1/8W 1% 145012
R9 RES SMD0805 4.75K 1/8W 1% 145008
R10 RES SMD0805 10 1/8W 1% 145017
R11 RES SMD0805 4.75K 1/8W 1% 145008
R12 RES SMD0805 4.75K 1/8W 1% 145008
R13 RES SMD0805 1K 1/8W 1% 145007
R14 RES SMD0805 150 1/8W 1% 145019
R15 RES SMD0805 150 1/8W 1% 145019
R16 RES SMD0805 4.75K 1/8W 1% 145008
R17 RES SMD0805 221K 1/8W 1% 145038
R18 RES SMD0805 221K 1/8W 1% 145038
R20 RES SMD0805 22.1 1/8W 1% 145003
R21 RES SMD0805 221K 1/8W 1% 145038
R22 RES SMD0805 22.1 1/8W 1% 145003
R23 RES SMD0805 18.2K 1/8W 1% 145031
R25 RES SMD0805 4.75K 1/8W 1% 145008
R26 RES SMD0805 2.21K 1/8W 1% 145024
R27 RES SMD0805 22.1 1/8W 1% 145003
R30 RES SMD0805 10K 1/8W 1% 145010
R31 RES SMD0805 1.82K 1/8W 1% 145023
R32 RES SMD0805 1K 1/8W 1% 145007
R33 RES SMD0805 10 1/8W 1% 145017
R36 RES SMD0805 22.1 1/8W 1% 145003
R37 RES SMD0805 100K 1/8W 1% 145014
R38 RES SMD0805 150K 1/8W 1% 145037
R39 RES SMD0805 47.5K 1/8W 1% 145013
R40 RES SMD0805 150K 1/8W 1% 145037
R41 RES SMD0805 22.1 1/8W 1% 145003
R42 RES SMD0805 332K 1/8W 1% 145039
R43 RES SMD0805 332K 1/8W 1% 145039
R44 RES SMD0805 100K 1/8W 1% 145014
