McIntosh MA12000 User Manual

21
select the BAL Input. Refer to figure 8.
14. Press and hold in the INPUT Control until
“RENAME: BAL, >BAL < ” appears on the
Display. The character “B” is flashing to indicate
it is ready to be changed. Refer to figure 9.
15. Rotate the VOLUME (ADJUST) Control to change
the character “B” to “M”. Refer to figure 10.
16. Rotate the INPUT Control until the character “A”
is flashing, then rotate the VOLUME (ADJUST)
Control to change the character “A” to “E”. Refer
to figure 11.
Repeat this process until the desired word is spelled
(in this case “MEDIA SVR”). Refer to Figure 17.
18. To save the new name, press and hold in the
INPUT Control until “SETUP: MEDIA SVR ON
/ Rename” appears on the Front Panel Information
SETUP MODE.
7. Rotate the INPUT Control until “SETUP: Inputs,
(Hold INPUT)” appears on the Information
Display.
8. Press and hold in the INPUT Control until
“SETUP: UNBAL 4, Off” appears on the Display.
If necessary rotate the INPUT Control to select the
UNBAL 4 Input. Refer to figure 6.
9. To switch the UNBAL 4 Input On, rotate the
VOLUME Control until the display indicates
“SETUP: UNBAL 4, On / Name”.
10. Exit the SETUP Mode by several presses of the
INPUT Control.
RENAME INPUT:
In the following example, the BAL (BALANCED)
Input will be renamed to MEDIA SVR).
The MA12000 Default Input Names (UNBAL 1,
BAL, COAX 1, etc.) as indicated on the Front Panel
Display can be customized to a different name up to
ten characters long (TUNER, CD PLAYER, etc.). The
available characters for renaming the input include the
following: ! < > * , / - _ 0 1 2 3 4 5 6 7 8 9 A B C D E
F G H I J K L M N O P Q R S T U V W X Y Z .
In the following example, the BAL Input will be
renamed to “MEDIA SVR”.
11. Press and hold in the INPUT Control to enter the
SETUP MODE.
12. Rotate the INPUT Control until “SETUP: Inputs,
(Hold INPUT)” appears on the Information
Display. Refer to figure 7.
13. Press and hold in the INPUT Control until
“SETUP: BAL, On / Rename” appears on the
Display. If necessary rotate the INPUT Control to
In the following example, the UNBAL 4 Input will be
switched Off.
Note: When an INPUT is swiched Off, its name
will no longer appear on the Front Panel
Information Display when using the INPUT
Control (Front Panel or Remote Control).
1. Press and hold in the INPUT Control to enter the
SETUP MODE.
2. Rotate the INPUT Control until “SETUP: Inputs,
(Hold INPUT)” appears on the Information
Display.
3. Press and hold in the INPUT Control until
“SETUP: UNBAL 4, On / Name (Hold INPUT)”
appears on the Display. If necessary rotate the
INPUT Control to select the UNBAL 4 Input.
Refer to figure 5.
4. To switch the UNBAL 4 Input Off, rotate the
VOLUME Control until the display indicates
“SETUP: UNBAL 4, Off”. Refer to figure 6.
5. Exit the SETUP Mode by several presses of the
INPUT Control.
In the following example, the UNBAL 4 Input will be
switched On.
Notes: 1. When an INPUT is swiched ON, its name will
appear on the Front Panel Information Display
when using the INPUT Control (Front Panel or
Remote Control).
6. Press and hold in the INPUT Control to enter the
Figure 6
SETUP: UNBAL 4
Off
Figure 8
SETUP: BAL
On / Rename
Figure 10
RENAME: BAL
>MAL <
Figure 11
RENAME: OPTI
>MEL <
Figure 7
SETUP: Inputs
(Hold INPUT)
Figure 9
RENAME: BAL
>BAL <
Figure 5
SETUP: UNBAL 4
On/Name (Hold INPUT)
Figure 17
RENAME: BAL
>MEDIA SVR <

McIntosh MA12000 Specifications

General

Number of Channels	2
Total Harmonic Distortion	0.005%
Preamplifier Output	1 balanced, 1 unbalanced
Digital Inputs	2 coaxial, 2 optical, 1 USB, 1 MCT
Home Theater PassThru	Yes
Tone Controls	Yes
Tone Bypass	Yes
Power Output	350 Watts per channel
Frequency Response	20Hz to 20kHz +0, -0.5dB
Dimensions	17.5" (44.45cm)
Damping Factor	40
Headphone Output	Yes
Phono Input	1 Moving Magnet, 1 Moving Coil
Power Requirement	120V, 60Hz
Standby Power Requirement	Less than 0.5 Watt
Input Impedance	20K ohms (unbalanced), 40K ohms (balanced)
Preamplifier Inputs	1 Balanced, 4 Unbalanced
