McIntosh MC1502 User Manual

12
Front Panel Controls and Indicators
POWER Switch Turns
AC Power ON, OFF
or REMOTE
Left Channel Small Signal Vacuum Tubes
LED Illumination Color Operation Mode Function
Amber Warm-up Audio Signal is muted
Green Normal Selected by Tube Light Control
Red (Flash Illumination) Sentry Protection Circuitry is Activated
Right Channel Small Signal Vacuum Tubes
LED Illumination Color Operation Mode Function
Amber Warm-up Audio Signal is muted
Green Normal Selected by Tube Light Control
Red (Flash Illumination) Sentry Protection Circuitry is Activated
ON
REMOTE
OFF
ON
POWER
TUBE LIGHTS
OFF
OFF
ON
NOF
TUBE LIGHTS
Selects ON or OFF
Standby Power
On Indicator
Front View Front Panel View Enlarged
Right Side View
TUBE LIGH TS POWE R
