Adequate ventilation extends the trouble free life of
the MC1502. Always allow air to flow through the
ventilation holes on the bottom of the amplifier and a
means for the warm air to escape at the top. Refer to
figure 10.
Allow at least 19 inches (48.3cm) above the top; 6
inches (15.2cm) for the Front, Rear and Sides; allow
1/2 inch (1.3cm) below the Power Amplifier so the
airflow is not obstructed.
